UL 1310 Class 2 Power Units Power Supply Product offering
The UL 1310, Class 2 Power Units, standard applies to power supplies within a limited output current and output voltage range.
The Class 2 standard is specified in UL Standard Number UL1310. In order to receive the UL Class 2 approval, the power supply must have the output current not exceeding 8 A and the output voltage may not exceed 30 VDC.
A benefit of using UL 1310 Class 2 approved GlobTek power supplies is that the output has the same Class 2 safety level. When applying for system level safety approval for the equipment, in some cases it is not necessary to obtain safety standard approval for the connected device (load) when the device (load) is connected to the output of a power supply that has received Class 2 approval.
UL1310 approved power supplies
| Name | Type | Input Voltage | Watts | Vout | Efficiency | Ingress Protection | MOOP | MOPP | 60601-1-4th Ed. | Dimensions (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| GT-335-XX-YYYYD | Wall Plug-in | 115V~ / 60Hz | 3 | 3.3-48 V | 96.5*97*36.5 | |||||
| GT-335A-9-500 | Wall Plug-in | 115V~ / 60Hz | 4.5 | 0 V | ||||||
| GT-C3051-W2E (1-5W) | Wall Plug-in | 100-240V~, 50-60 Hz | 5 | 3-12 V | V | |||||
| GT-C3052-W2 (1-6W) | Wall Plug-in | 100-240V~, 50-60 Hz | 6 | 3-12 V | V | |||||
| GTM96060-06VV-Q | Wall Plug-in | 100-240V~, 50-60 Hz | 6 | 3.3-48 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP42 (Optional IP54-IP55) | ☑ | ☑ | 43.5*74.0*36.8 | |
| GTM96060CC06VV-Q | Wall Plug-in | 100-240V~, 50-60 Hz | 6 | 6.2-16 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP52 (Optional IP54-IP55) | ☑ | ☑ | 43.5*74.0*36.8 | |
| GT-C3052-W2A (1-6W) | Wall Plug-in | 100-240V~, 50-60 Hz | 6 | 3-12 V | V | |||||
| GTM43033-Q | Wall Plug-in | 100-240V~, 50-60 Hz | 6 | 3-48 V | V | IP52 | ☑ | 74*44*34 | ||
| GT-C3052-W2U (1-6W) | Wall Plug-in | 100-240V~, 50-60 Hz | 6 | 3-12 V | V | |||||
| GTM41134-06VV-Q | Wall Plug-in | 100-240V~, 50-60 Hz | 6 | 3.3-48 V | V | IP52 | ☑ | ☑ | 43.5*74.0*35.3 | |
| GT-C3052-W2E (1-6W) | Wall Plug-in | 100-240V~, 50-60 Hz | 6 | 3-12 V | V | Indoor Use | ||||
| GT-341-12-500D | Wall Plug-in | 120V~ /60Hz | 6 | 12 V | 77.50.0*41.5 | |||||
| GT-41052-WWVV-X.X-Q Class 2 | Wall Plug-in | 100-240V~, 50-60 Hz | 15 | 12 V | V/IV see Approvals | IP52 | 43.5* 74.0* 35.3 | |||
| GTM46161-16V.V-USB | Wall Plug-in | 100-240V~, 50-60 Hz | 16 | 5 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | Indoor Use | ☑ | ☑ | 71.00*41.00*31.50 | |
| GTM41080-18VV H/M | Wall Plug-in | 100-240V~, 50-60 Hz | 18 | 5-48 V | V | IP52 | ☑ | ☑ | 74*44*34 | |
| GTM96180-18VV-T3 | Desktop/External | 100-240V~, 50-60 Hz | 18 | 5-48 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP42 | ☑ | ☑ | (L)87x(W)47x(H)32mm | |
| GTM96180-18VV H/M | Wall Plug-in | 100-240V~, 50-60 Hz | 18 | 3-48 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP42 (Optional IP54-IP55) | ☑ | ☑ | 74*43.5*36.8 | |
| GTM41080-36.1-48V-M-IP40 | Wall Plug-in | 100-240V~, 50-60 Hz | 18 | 6-48 V | V | IP40 Standard, IP52 Optional | ☑ | ☑ | ☑ | 74*44*34 |
| GTM96180-18VV-T2 | Desktop/External | 100-240V~, 50-60 Hz | 18 | 5-48 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP42 | ☑ | ☑ | (L)87x(W)47x(H)32mm | |
| GTM96180-18VV-T2A | Desktop/External | 100-240V~, 50-60 Hz | 18 | 5-48 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP42 | ☑ | ☑ | (L)87x(W)47x(H)32mm | |
| GTM96180-18VV-T3A | Desktop/External | 100-240V~, 50-60 Hz | 18 | 5-48 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP42 | ☑ | ☑ | 87.0 x 46.5 x 32.0 | |
| GTM93021-20VV-T2 (terminal block and wires) | Potted/Encapsulated in plastic housing | 100-240V~, 50-60 Hz | 20 | 5-48 V | V | IP68 | 48.0*51.0*35 | |||
| GTM93021-20VV-P2 (Variable output connector) | Potted/Encapsulated in plastic housing | 100-240V~, 50-60 Hz | 20 | 5-48 V | V | IP68 | 51.0*48.0*35.0 | |||
| GTM93021-20VV-P2 (WIRES-push in Wago+ KCC)) Einbau-Netzteil Unterputz Inst | Potted/Encapsulated in plastic housing | 100-240V~, 50-60 Hz | 20 | 5-48 V | V | IP68 | 51.0*48.0*35.0 | |||
| GTM93021-20VV-P2 (with loose cables on Input and Output Side) | Potted/Encapsulated in plastic housing | 100-240V~, 50-60 Hz | 20 | 5-48 V | V | IP68 | 42.8*39.8*35.0 | |||
| GTM93021-20VV-P2 (WIRES) | Potted/Encapsulated in plastic housing | 100-240V~, 50-60 Hz | 20 | 5-48 V | V | IP68 | 51.0*48.0*35.0 | |||
| GTM93021-20VV-T2 (terminal block) Einbau-Netzteil für Unterputz Installation | Potted/Encapsulated in plastic housing | 100-240V~, 50-60 Hz | 20 | 5-48 V | V | IP68 | 48.0*51.0*35 | |||
| GTM93021-20VV-D2 (PCB Mount/Pins) Unterputz Netzteil | Potted/Encapsulated in plastic housing | 100-240V~, 50-60 Hz | 20 | 5-48 V | V | IP68 | 48*51*35 | |||
| GTM96300-36VV-T2A | Desktop/External | 100-240V~, 50-60 Hz | 36 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP42, IP54 Option available | ☑ | ☑ | (L)107.2.0x(W)50.0x(H)35.50mm | |
| GTM96300-36VV-T2 | Desktop/External | 100-240V~, 50-60 Hz | 36 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP42, IP54 Option available | ☑ | ☑ | (L)107.2.0x(W)50.0x(H)35.50mm | |
| GTM96300-36VV-T3A | Desktop/External | 100-240V~, 50-60 Hz | 36 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP42, IP54 Option available | ☑ | ☑ | (L)107.2x(W)50.0x(H)35.0 | |
| GTM96300-36VV-R3A | Wall Plug-in+Desktop Combination | 100-240V~, 50-60 Hz | 36 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP40 (cord), IP52(R-blades) | ☑ | ☑ | 102.19 x 47.5 x 36.7 | |
| GTM96300-36VV-T3 | Desktop/External | 100-240V~, 50-60 Hz | 36 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP42, IP54 Option available | ☑ | ☑ | 107.2x(W)50.0x(H)35.0mm | |
| GTM96300-36VV-R2 | Wall Plug-in+Desktop Combination | 100-240V~, 50-60 Hz | 36 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP40 (cord), IP52(R-blades) | ☑ | ☑ | (L)101.73x(W)46.47x(H)38.2mm | |
| GTM46402-40VV-x.x-Q | Wall Plug-in | 100-240V~, 50-60 Hz | 40 | 5-48 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | Indoor Use | ☑ | ☑ | 43.5 x 74.0 x 35.3 | |
| GT-43007-40VV-Q(-40Deg) | Wall Plug-in | 100-240V~, 50-60 Hz | 40 | 12-48 V | V | IP52 | ||||
| GT-43007-40VV-Q | Wall Plug-in | 100-240V~, 50-60 Hz | 40 | 12-48 V | V | IP52 | 43.5 x 74.0 x 35.3 | |||
| GTM93055-WWVV-X.X-Q | Wall Plug-in | 100-240V~, 50-60 Hz | 45 | 5-48 V | V | ☑ | 74*44*34 | |||
| GTM96600-60VV.V-T2 | Desktop/External | 100-240V~, 50-60Hz | 60 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP41 | ☑ | ☑ | 117.5*53.5*34.2 | |
| GTM96600-60VV.V-R2 | Wall Plug-in+Desktop Combination | 100-240V~, 50-60 Hz | 60 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP40, IP54 Option available | ☑ | ☑ | 117.53*53.47*36.6 | |
| GTM96600-60VV.V-T2A | Desktop/External | 100-240V~, 50-60Hz | 60 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP41 | ☑ | ☑ | 117.5*53.5*34.2 | |
| GTM96600-60VV.V-T3 | Desktop/External | 100-240V~, 50-60Hz | 60 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP41 | ☑ | ☑ | 117.5*53.5*34.2 | |
| GTM96600-60VV.V-T3A | Desktop/External | 100-240V~, 50-60Hz | 60 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP41 | ☑ | ☑ | 117.5*53.5*34.2 | |
| GTM96600-60VV-P2(SR with NA Plug 2 pin) | Potted/Encapsulated in plastic housing | 100-240V~, 50-60 Hz | 60 | 5-48 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP68 | ☑ | ☑ | 114.81*57.11*39.0 | |
| GTM96600-60VV-P3(SR with fixed Plug 3 pin) | Potted/Encapsulated in plastic housing | 100-240V~, 50-60 Hz | 60 | 0 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP68 | ☑ | ☑ | 114.81*57.11*39.0 | |
| GTM96600-65VV-P2(SR with fixed Plug 2 pin) | Potted/Encapsulated in plastic housing | 100-240V~, 50-60 Hz | 60 | 0 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP68 | ☑ | ☑ | 114.81*57.11*39.0 | |
| GTM96600-60VV.V-R3A | Wall Plug-in+Desktop Combination | 100-240V~, 50-60 Hz | 60 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP40, IP54 Option available | ☑ | ☑ | 117.53*53.47*36.6 | |
| GTM96600-60VV.V-R2L | Wall Plug-in+Desktop Combination | 100-240V~, 50-60 Hz | 60 | 48 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP40, IP54 Option available | ☑ | ☑ | 136.3*54.1*37.6 | |
| GTM96600-65VV.V-R3A | Wall Plug-in+Desktop Combination | 100-240V~, 50-60 Hz | 65 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP40, IP54 Option available | ☑ | ☑ | 117.53*53.47*36.6 | |
| GTM96600-65VV.V-T2A | Desktop/External | 100-240V~, 50-60Hz | 65 | 5-48 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP41 | ☑ | ☑ | 117.5*53.5*34.2 | |
| GTM96600-65VV.V-P3(SR with fixed Plug 3 pin) | Potted/Encapsulated in plastic housing | 100-240V~, 50-60Hz | 65 | 0 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP68 | ☑ | ☑ | 114.81*57.11*39.00 | |
| GTM96600-65VV.V-P2 | Potted/Encapsulated in plastic housing | 100-240V~, 50-60Hz | 65 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP68 | ☑ | ☑ | 114.81*57.11*39.00 | |
| GTM96600-65VV.V-T3 | Desktop/External | 100-240V~, 50-60Hz | 65 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP41 | ☑ | ☑ | 117.5*53.5*34.2 | |
| GTM96600-65VV.V-P3 | Potted/Encapsulated in plastic housing | 100-240V~, 50-60Hz | 65 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP68 | ☑ | ☑ | 114.81*57.11*39.00 | |
| GTM96600-65VV.V-T2 | Desktop/External | 100-240V~, 50-60Hz | 65 | 5-48 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP41 | ☑ | ☑ | 117.5*53.5*34.2 | |
| GTM96600-65VV.V-R2L | Wall Plug-in+Desktop Combination | 100-240V~, 50-60 Hz | 65 | 5-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP40, IP54 Option available | ☑ | ☑ | 136.3*54.1*37.6 | |
| GTM96600-65VV.V-R2 | Wall Plug-in+Desktop Combination | 100-240V~, 50-60 Hz | 65 | 12-48 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP40, IP54 Option available | ☑ | ☑ | 117.53*53.47*36.6 | |
| GTM96600-65VV.V-T3A | Desktop/External | 100-240V~, 50-60Hz | 65 | 5-48 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP41 | ☑ | ☑ | 117.5*53.5*34.2 | |
| GTM96900P90VV.V-T3A | Desktop/External | 100-240V~, 50-60Hz | 90 | 12-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP41 | ☑ | ☑ | 149.3 x 62.8 x 34.0 +/-1.0 | |
| GTM96900P90VV.V-T2 | Desktop/External | 100-240V~, 50-60 Hz | 90 | 12-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP41 | ☑ | 149.3 x 62.8 x 34.0 +/-1.0 | ||
| GTM96900P90VV.V-T3 | Desktop/External | 100-240V~, 50-60Hz | 90 | 12-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | IP41 | ☑ | ☑ | 149.3 x 62.8 x 34.0 +/-1.0 | |
| GTM43004P-WWVV-x.x-P2 | Potted/Encapsulated in plastic housing | 100-240V~, 50-60 Hz | 120 | 5-48 V | V | IP68 | 178.0*76.0*39.5 mm | |||
| GTM43004P-WWVV-x.x-P3 | Potted/Encapsulated in plastic housing | 100-240V~, 50-60 Hz | 120 | 5-48 V | V | IP68 | ☑ | 178.0*76.0*39.5 | ||
| GTM43004P-WWVV-x.x-P3 (SR with NA Plug 3 pin) | Potted/Encapsulated in plastic housing | 100-240V~, 50-60 Hz | 120 | 9-30 V | V | IP68 | ☑ | 178.0*76.0*39.5 | ||
| GTM962500PWWWVV.V-F | Open Frame/Internal | 100-240V~, 50-60 Hz | 250 | 12-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | na | ☑ | ☑ | 203*63.5*41 | |
| GTM962500PWWWVV.V-FL | Open Frame/Internal | 100-240V~, 50-60 Hz | 250 | 12-54 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | na | ☑ | ☑ | 203*63.5*41 | |
| GTM962500PWWWVV.V-CX | Open Frame/Internal | 100-240V~, 50-60 Hz | 250 | 15-36 V | USA DOE Level VI / Eco-design Directive 2009/125/EC, (EU) 2019/1782 | na | ☑ | ☑ | 203*63.5*41 |
